Rigid PCB

SERIAL

ITEM

TECHNICAL DATA

1

Types of Products

HDL Multilayer PCB, Buried/Blind Via Board, High Frequency Board, Aluminum Base Board Flex-Rigid PCB，FPC, Teflon Board, and HDI

2

Layers

0－50(layers)

3

Materials

FR-4,High Tg FR-4,Halogen free,High Frequency
(Rogers,Arlon,Taconic,Nelco...)etc.

4

Max Board Size

22.5″* 49″

5

Board Thickness

0.2mm-8.0mm

6

Copper Clad(Max.)

6 oz(outer)/4 oz(inner)

7

Min line Width/space

0.075mm    3mil

8

Drill Size Mechanical (min)

0.10mm 4mil

9

Drill Size Laser(min)

0.10mm 4mil

10

PTH Wall Thickness

0.020mm 0.8mil

11

PTH dia tolerance

±0.075mm ±3mil

12

NPTH hole dia tolerance

±0.05mm ±2mil

13

Hole Position Deviation

±0.05mm ±2mil

14

Outline Tolerance

±0.10mm ±4mil

15

S/M Pitch

0.08mm 3mil

16

Insulation Resistance

1E+12Ω(Normal)

17

Test Voltage

50~300V

18

Max Aspect Ratio

40：1

19

Thermal Shock

3x10Sec@288 ℃

20

Warp and Twist

≤0.7%

21

Current breakdown

10A

22

Electric Strength

＞1.3KV/mm

23

Peel Strength

1.4N/mm

24

Solder Mask Abrasion

≥6H

25

Flammability

94V-0

26

Impedance Control

+/-10%(Differential)

27

Buried Via

Yes

28

Blind Via

Yes

29

HDI

1+N+1, 2+N+2, 3+N+3, 4+N+4 4mil Via hole

30

Surface Finished

HASL, ENIG, ENEPIG, Immersion Silver, Immersion Tin, Flash Gold, Golden Finger, OSP, Lead free HASL etc
